您的位置:网站首页 > 产品展示 - ST/意法

ST/意法

ST可控硅系列

    标准三端双向可控硅开关是一种通用AC电源开关，采用简单的小电流栅极驱动器。 它们是一种具有无火花和无老化特性的半导体器件，适于各种以市电为电源的电器。 栅极简单的相位角滞后点火让我们能够轻松调节照明亮度和通用电机的速度。

    无缓冲三端双向可控硅开关特别适于具有增强型关断能力的三象限、感应负载设计。 这些器件的反向电压高达800 V、最大电流高达40 A。意法半导体’提供了全面的通孔和SMD封装产品：TO-92、SOT-223、DPAK、IPAK、TO-202-3、D²PAK、I²PAK、ISOWATT-220、TO-220(I)、RD-91和TOP-3。

    T系列高性能三端双向可控硅开关专为工业控制和家用电器内的AC负载而设计，实现了创新型安全AC负载控制。这款高性能T系列产品的抗扰度（dV/dt）和换向能力（dI/dt）分别是先进三端双向可控硅开关的2倍和5倍，提高了电路的抗EMI能力，并且能够全面控制负载，而没有任何干扰。其低至10 mA的栅电流有助于优化电源，并且能够通过微控制器与三端双向可控硅开关之间的单电阻实现直接驱动能力。T系列三端双向可控硅开关采用TO-220AB和TO-220FPAB封装。

常用型号：

Part
Number 		IT(RMS)
max (A) 		VDRM
max (V) 		ITSM
max (A) 		(Tj)
max(°C) 		IGT (I,II,III)
max(mA) 		 IGT(I, II,III,I)
max(mA) 		Package
Z00607 0.8 600 9 110 5,5,5,7 TO-92
Z0103M 1 600 8 125 3,3,3,5 SOT-223,TO-92
Z0107M 1 600 8 125 5,5,5,7 SOT-223,TO-92
Z0109M 1 600 8 125 10,10,10,10 SOT-223,TO-92
Z0103NA/NN 1 800 8 125 3,3,3,5 SOT-223,TO-92
Z0107NA/NN 1 800 8 125 5,5,5,7 SOT-223,TO-92
Z0109NA/NN 1 800 8 125 10,10,10,10 SOT-223,TO-92
Z0110N 1 800 8 125 25,25,25,25 SOT-223,TO-92
Z0405MF 4 600 20 125 5,5,5,5 TO-202-3
Z0409MF 4 600 20 125 10,10,10,10 TO-202-3
Z0410MF 4 600 20 125 25,25,25,25 TO-202-3
BTA04-600S 4 600 40 110 10,10,10,10 TO-220AB
Z0405SF 4 700 20 125 5,5,5,5 TO-202-3
Z0409SF 4 700 20 125 10,10,10,10 TO-202-3
Z0410SF 4 700 20 125 25,25,25,25 TO-202-3
T405 4 600 to 800 30 125 5,5,5 TO-220
T410 4 600 to 800 30 125 10,10,10 TO-220
Z0405NF 4 800 20 125 5,5,5,5 TO-202-3
Z0409NF 4 800 20 125 10,10,10,10 TO-202-3
Z0410NF 4 800 20 125 25,25,25,25 TO-202-3
BTB06-600B 6 600 60 125 50,50,50,100 TO-220AB
BTB06-600BW 6 600 60 125 50,50,50 TO-220AB
BTB06-600C 6 600 60 125 25,25,25,50 TO-220AB
BTB06-600CW 6 600 60 125 35,35,35 TO-220AB
BTB06-600SW 6 600 60 125 10,10,10 TO-220AB
BTB06-600TW 6 600 60 125 5,5,5 TO-220AB
BTA06-600B 6 600 60 125 50,50,50,100 TO-220AB
BTA06-600BW 6 600 60 125 50,50,50 TO-220AB
BTA06-600C 6 600 60 125 25,25,25,50 TO-220AB
BTA06-600CW 6 600 60 125 35,35,35 TO-220AB
BTA06-600SW 6 600 60 125 10,10,10 TO-220AB
BTA06-600TW 6 600 60 125 5,5,5, TO-220AB
BTB06-800B 6 800 60 125 50,50,50,100 TO-220AB
BTB06-800BW 6 800 60 125 50,50,50 TO-220AB
BTB06-800C 6 800 60 125 25,25,25,50 TO-220AB
BTB06-800CW 6 800 60 125 35,35,35 TO-220AB
BTB06-800SW 6 800 60 125 10,10,10 TO-220AB
BTB06-800TW 6 800 60 125 5,5,5, TO-220AB
BTA06-800B 6 800 60 125 50,50,50,100 TO-220AB
BTA06-800BW 6 800 60 125 50,50,50 TO-220AB
BTA06-800C 6 800 60 125 25,25,25,50 TO-220AB
BTA06-800CW 6 800 60 125 35,35,35 TO-220AB
BTA06-800SW 6 800 60 125 10,10,10 TO-220AB
BTA06-800TW 6 800 60 125 5,5,5, TO-220AB
BTB08-600B 8 600 80 125 50,50,50,100 TO-220AB
BTB08-600BW 8 600 80 125 50,50,50 TO-220AB
BTB08-600C 8 600 80 125 25,25,25,50 TO-220AB
BTB08-600CW 8 600 80 125 35,35,35 TO-220AB
BTB08-600SW 8 600 80 125 10,10,10 TO-220AB
BTB08-600TW 8 600 80 125 5,5,5, TO-220AB
BTA08-600B 8 600 80 125 50,50,50,100 TO-220AB
BTA08-600BW 8 600 80 125 50,50,50 TO-220AB
BTA08-600C 8 600 80 125 25,25,25,50 TO-220AB
BTA08-600CW 8 600 80 125 35,35,35 TO-220AB
BTA08-600SW 8 600 80 125 10,10,10 TO-220AB
BTA08-600TW 8 600 80 125 5,5,5, TO-220AB
BTB08-800B 8 800 80 125 50,50,50,100 TO-220AB
BTB08-800BW 8 800 80 125 50,50,50 TO-220AB
BTB08-800C 8 800 80 125 25,25,25,50 TO-220AB
BTB08-800CW 8 800 80 125 35,35,35 TO-220AB
BTB08-800SW 8 800 80 125 10,10,10 TO-220AB
BTB08-800TW 8 800 80 125 5,5,5, TO-220AB
BTA08-800B 8 800 80 125 50,50,50,100 TO-220AB
BTA08-800BW 8 800 80 125 50,50,50 TO-220AB
BTA08-800C 8 800 80 125 25,25,25,50 TO-220AB
BTA08-800CW 8 800 80 125 35,35,35 TO-220AB
BTA08-800SW 8 800 80 125 10,10,10 TO-220AB
BTA08-800TW 8 800 80 125 5,5,5, TO-220AB
T810 8 800 80 125 10,10,10 D2PAK,DPAK
T835 8 800 80 125 35,35,35 D2PAK,DPAK
BTB10-600BW 10 600 100 125 50,50,50 TO-220AB
BTB10-600B 10 600 100 125 50,50,50,100 TO-220AB
BTB10-600C 10 600 100 125 25,25,25,50 TO-220AB
BTB10-600CW 10 600 100 125 35,35,35 TO-220AB
BTA10-600BW 10 600 100 125 50,50,50 TO-220AB Ins
T1235-600G 12 600 120 125 35,35,35 D2PAK
BTB12-800B 12 600 120 125 50,50,50,100 TO-220AB
BTB12-800BW 12 600 120 125 50,50,50 TO-220AB
BTB12-800C 12 600 120 125 25,25,25,50 TO-220AB
BTB12-800CW 12 600 120 125 35,35,35 TO-220AB
BTB12-800SW 12 600 120 125 10,10,10 TO-220AB
BTB12-800TW 12 600 120 125 5,5,5, TO-220AB
BTA12-600BW 12 600 120 125 50,50,50 TO-220AB
BTA12-600C 12 600 120 125 25,25,25,50 TO-220AB
BTA12-600CW 12 600 120 125 35,35,35 TO-220AB
BTA12-600SW 12 600 120 125 10,10,10 TO-220AB
BTA12-600TW 12 600 120 125 5,5,5, TO-220AB
BTB12-600B 12 800 120 125 50,50,50,100 TO-220AB
BTB12-600BW 12 800 120 125 50,50,50 TO-220AB
BTB12-600C 12 800 120 125 25,25,25,50 TO-220AB
BTB12-600CW 12 800 120 125 35,35,35 TO-220AB
BTB12-600SW 12 800 120 125 10,10,10 TO-220AB
BTB12-600TW 12 800 120 125 5,5,5, TO-220AB
BTA12-600B 12 800 120 125 50,50,50,100 TO-220AB
BTA12-800B 12 800 120 125 50,50,50,100 TO-220AB
BTA12-800BW 12 800 120 125 50,50,50 TO-220AB
BTA12-800C 12 800 120 125 25,25,25,50 TO-220AB
BTA12-800CW 12 800 120 125 35,35,35 TO-220AB
BTA12-800SW 12 800 120 125 10,10,10 TO-220AB
BTA12-800TW 12 800 120 125 5,5,5, TO-220AB
BTB16-600B 16 600 160 125 50,50,50,100 TO-220AB
BTB16-600BW 16 600 160 125 50,50,50 TO-220AB
BTB16-600C 16 600 160 125 25,25,25,50 TO-220AB
BTB16-600CW 16 600 160 125 35,35,35 TO-220AB
BTB16-600SW 16 600 160 125 10,10,10 TO-220AB
BTA16-600B 16 600 160 125 50,50,50,100 TO-220AB
BTA16-600BW 16 600 160 125 50,50,50 TO-220AB
BTA16-600C 16 600 160 125 25,25,25,50 TO-220AB
BTA16-600CW 16 600 160 125 35,35,35 TO-220AB
BTA16-600SW 16 600 160 125 10,10,10 TO-220AB
BTA16-600TW 16 600 160 125 5,5,5, TO-220AB
BTB16-800B 16 800 160 125 50,50,50,100 TO-220AB
BTB16-800BW 16 800 160 125 50,50,50 TO-220AB
BTB16-800CW 16 800 160 125 35,35,35 TO-220AB
BTB16-800SW 16 800 160 125 10,10,10 TO-220AB
BTA16-800B 16 800 160 125 50,50,50,100 TO-220AB
BTA16-800BW 16 800 160 125 50,50,50 TO-220AB
BTA16-800CW 16 800 160 125 35,35,35 TO-220AB
BTA16-800SW 16 800 160 125 10,10,10 TO-220AB
BTA16-800TW 16 800 160 125 5,5,5, TO-220AB
BTA20-600CW 20 600 200 125 35,35,35 TO-220AB
BTA24-600BW 25 600 250 125 50,50,50 TO-220AB
BTA24-600CW 25 600 250 125 35,35,35 TO-220AB
BTB24-600B 25 600 250 125 50,50,50,100 TO-220AB
BTB24-600BW 25 600 250 125 50,50,50 TO-220AB
BTB24-600CW 25 600 250 125 35,35,35 TO-220AB
BTA25-600B 25 600 250 125 50,50,50,100 RD-91
BTA25-600BW 25 600 250 125 50,50,50 RD-91
BTA25-600CW 25 600 250 125 35,35,35 RD-91
BTA26-600B 25 600 250 125 50,50,50,100 TOP-3
BTA26-600BW 25 600 250 125 50,50,50 TOP-3
BTA26-600CW 25 600 250 125 35,35,35 TOP-3
BTB26-600B 25 600 250 125 50,50,50,100 TOP-3
T2535-800G 25 800 250 125 35,35,35 D2PAK
BTA24-800BW 25 800 250 125 50,50,50 TO-220AB
BTA24-800CW 25 800 250 125 35,35,35 TO-220AB
BTB24-800B 25 800 250 125 50,50,50,100 TO-220AB
T435T-600FP 4 600 30 125 35,35,35 TO-220FPAB
T610T-8T 6 800 45 125 10,10,10 TO-220AB
T810T-6I 8 600 60 125 10,10,10 TO-220AB
T835T-6I 8 600 60 125 35,35,35 TO-220AB
T1210T-6I 12 600 90 125 10,10,10 TO-220AB
T1225T-6I 12 600 90 125 25,25,25,40 TO-220AB
T1235T-6I 12 600 90 125 35,35,35 TO-220AB
T1610T-8I 16 800 120 125 10,10,10 TO-220AB
T1620T-8I 16 800 120 125 20,20,20 TO-220AB
T1625T-8I 16 800 120 125 25,25,25,50 TO-220AB
T1635T-8I 16 800 120 125 35,35,35 TO-220AB
T1635T-8T 16 800 120 125 35,35,35 TO-220AB
T810H 8 600 80 150 10,10,10 TO-220AB
T835H-6I 8 600 80 150 35,35,35 TO-220
T1235H-6I 12 600 120 150 35,35,35 TO-220
T1635H-6I 16 600 160 150 35,35,35 TO-220
T2035H-6I 20 600 200 150 35,35,35 TO-220
T3035H-6I 30 600 270 150 35,35,35 TO-220
